Appendix
A.3 List of accessible system variables
Expanding the user interface
A-16 Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
Name Index Description
$TC_MAP3 Status of magazine
$TC_MAP4 Link 1 between magazine and next magazine
$TC_MAP5 Link 2 between magazine and preceding
magazine
$TC_MAP6 Magazine dimension
$TC_MAP9 Number of active wear group
$TC_MAPCx[y] x=ParameterNo
y=MagazineNo
Magazine user data for a tool magazine
$TC_MOP1(x,y) … $TC_MOP15(x,y) x=ToolNo
y=EdgeNo
Monitoring data for each tool edge
$TC_MOPCx[y,z] x=ParamNo,
y=T number
z=Edge
Magazine user data for a tool edge
$TC_MPPCx[y,z] x= ParamNo
y= MagazineNo
z= MagPlaceNo
Magazine location user data for a tool
magazine
$TC_MPPx x=1,...7 No. of parameters per magazine location
$TC_SCP... Transformed location-dependent wear
correction
$TC_SCP... Location-dependent wear correction
$TC_SCPx x=13,...21,....71 Number of total offset parameters per total
offset block
$TC_TP1 DUPLO number
$TC_TP10 Tool search type for replacement tools
$TC_TP11 Tool information for HMI
$TC_TP2 Tool designation
$TC_TP3 Size to left in half locations
$TC_TP4 Size to right in half locations
$TC_TP5 Size upwards in half locations
$TC_TP6 Size downwards in half locations
$TC_TP7 Magazine location type
$TC_TP8 Tool status
$TC_TP9 Tool monitoring method
$TC_TPCx[y] x=ParameterNo
y = ToolNo
User-defined tool parameter
$TC_TPG1 Spindle number
$TC_TPG2 Chaining rule
$TC_TPG3 Minimum wheel diameter
$TC_TPG4 Minimum grinding wheel width
$TC_TPG5 Current width of grinding wheel
$TC_TPG6 Maximum speed of grinding wheel
$TC_TPG7 Maximum peripheral speed of grinding wheel
(SUG)
$TC_TPG8 Angle of inclination of inclined grinding wheel
