Editing files with Word
2.4 Saving text files
Generating target language texts (TX2)
14 Commissioning Manual, 11/2006, 6FC5397-0DP10-0BA0
7. Click "OK".
The file is opened and converted to a Word file at the same time.
The existing text is formatted using a default font.
2.4 Saving text files
Save the text entered as a "Text File":
1. In Word, select "Save As…" from the "File" menu.
2. Choose the option "Text Only (*.txt)" under "Save as type".
3. Enter the name of the file in the "File name" box and click "Save".
– The "File Conversion" dialog box will then appear.
– Select the encoding which is suitable for your target language and click "OK". Section
"Codes for SINUMERIK HMI", Table 2-1 lists the suitable encoding options.
– Your file is now saved as a text file and encoded using the selected code page in the
process.
