3RT1/3RH1 contactors
SIRIUS System Manual
3-82
GWA 4NEB 430 0999-02b
Removing the spring
If necessary, the spring for attachment to the rail can be removed before the
soldering pin connection is mounted.
Figure 3-65: Removing the spring from the soldering pin connection
1
2
