3RA1 fuseless load feeders
SIRIUS System Manual
GWA 4NEB 430 0999-02b
5-17
Figure 5-11: Self-assembly, busbars, reversing operation (frame size S2)
4
1
4
4
2
3
5
3RA1931-1.
3RA1904-2B
S2
Kit 3RA1933-1.
