3RP10, 3RP15 solid-state time relays
SIRIUS System Manual
7-10
GWA 4NEB 430 0999-02b
Function diagrams
The coding plug set contains the functions for the 3RP1000 solid-state time
relay listed in the following table:
Important
The same potential must be applied to terminals A and B.
A./A2
q
A1/A2 or A3/A2, depending on the voltage level connected
B./A2
q
B1/A2 or B3/A2, depending on the voltage level connected
Function Circuit diagram Function diagram
On-delay
Off-delay with aux-
iliary supply
On-delay and off-
delay with auxil-
iary supply
Flashing,
start with break
Making pulse con-
tact
Breaking pulse con-
tact with auxiliary
supply
Shaping pulse con-
tact with auxiliary
supply
Table 7-2: 3RP10 00 (multifunctional) circuit diagrams and function diagrams
15 C
16 NC 18 NO
A.
A2
ansprechverzögert
ON DELAY
t
A./A2
15/18
15/16
15 C
A2
A. B.
rückfallverzögert
OFF DELAY
16 NC 18 NO
A./A2
≥
35 ms
B./A2
15/18
15/16
t
15 C
A2
A. B.
ansprech-/rückfallverzögert
ON/ OFF DELAY
16 NC 18 NO
A./A2
B./A2
15/18
15/16
t
an
t
ab
t
an
=
t
ab
15 C
16 NC 18 NO
Blinker
FLASHER
A.
A2
t
A./A2
15/18
15/16
t
15 C
16 NC 18 NO
Wischer Ein
IMPULSE ON
A.
A2
t
A./A2
15/18
15/16
15 C
A. B.
16 NC 18 NO
Wischer Aus
A2
IMPULSE OFF
t
A./A2
B./A2
15/18
15/16
≥
35 ms
Impulsformung
PULSE SHAPING
15 C
A.
B.
16 NC 18 NO
A2
t
≥
35 ms
A./A2
B./A2
15/18
15/16
