Setting 0.0 to 50m
Default 2m
Near range suppression distance threshold (3.3.4.4)
Se
ts minimum distance of selected echo for near range suppression.
Setting 0.0 to 12.0 m
Default 1.2m
Near range suppression echo strength threshold (3.3.4.5)
Se
ts minimum amplitude of selected echo for near range suppression.
Setting 0 to 99
Default 40 dB
Near range suppression expiry time (3.3.4.6)
De󹪝nes
the time (in hours) to disable near range suppression, if conditions not met (0 = never).
Setting 0 to 65 535
Default 168 hrs
Number of shots (3.3.4.7)
Se
ts number of shots to be 󹪝red (and results averaged) per transmit pulse.
Setting 1 to 25
Default 10
A higher number of shots may result in a reduction in variation of the reported measurement
v
alue, but can increase the update time between measurements.
9.3.3.5 Sampling (3.3.5)
Echo lock (3.3.5.1)
Sets measurement veri󹪝cation process. When echo lock set to "Total lock", parameter "Echo lock
window" is preset to 0 for automatic width and cannot be changed.
Setting Disabled
Maximum v
eri󹪝cation
Material agitator
Total lock
Default Material agitator
Parameter assignment
9.3Maintenance and diagnostics (3)
SITRANS LR500 series with mA/HART
Operating Instructions, 03/2024, A5E51099898-AA 135
