Operating conditions and structural design î™
Input voltage range 2.2 ... 3.4 V DC
Maximum current consumption 2.5 mA
Material Polycarbonate
Torque for cable gland 10 Nm (7.38 ft lb)
Communication, interface Bluetoothî™ 4.2
Range Class 2; approx. 10î™ m
Radio approvals Contains FCC ID: RYYEYSHJN
Cont
ains IC: 4389B-EYSHJN
CMIIT ID: 2020DJ15120
D.2.7 Technical data: SITRANS mobile IQ
Software requirements î™
Bluetooth BLEî™ 4.2 or higher
D.2.8 Dimensions SITRANS AW050 Bluetooth adapter





Dimension drawing SITRANSî™ AW050 Bluetooth adapter, dimensions in mm (inch)
Remote operation
D.2î™ Bluetooth
SITRANS LR500 series with mA/HART
Operating Instructions, 03/2024, A5E51099898-AA 213
