7.5 Gather parameter values before running quick start wizards
Bef
ore initiating a Quick start wizard to congure the device, you may wish to gather the
necessary parameter values. Parameter conguration charts that list all parameters and
available options for each application type are available on our website.
Go to Product page (
www.siemens.com/sitransLR500).
Clic
k "Support > Application Guides".
Record data and select from options on the chart that apply to your application, then with
this data on hand, complete the quick start wizards.
7.6 Local commissioning
SITRANS LR500 series can be quickly commissioned using wizards, and menu driven parameters.
The parameters can be modied locally using the device display and buttons, also known as the
Human Machine Interface (HMI).
① Local device buttons
The quick start wizards provide an easy step-by-step procedure to help you congure the
device for a simple application. We recommend that you congure your application in the
following order:
• First, run the "Quick commissioning wizard" for your application.
• Next, if there are known false echoes present, run the "Auto false echo suppression wizard"
(optional) to prevent false echo detection when the vessel is empty or below the false echo
level.
• After completing the wizards, congure any custom parameters via the parameter menus.
You can access the quick commissioning wizards:
• Locally via HMI
• From a remote location via mobile IQ, app with AW050 module or SIMATIC PDM EDD
7.6.1 Activating SITRANS LR500 series
Power up the device.
SITRANS LR500 series runs through an initialization routine for approximately 30 seconds
or less. Next, the device name and then rmware revision appear. The display goes into
measurement view (measured process values show as "- - - - -" before the rst measurement
Commissioning
7.6Local commissioning
SITRANS LR500 series with mA/HART
64 Operating Instructions, 03/2024, A5E51099898-AA
