6.1.4 Improvement of interference immunity
Note
Im
provement of interference immunity
• Lay signal cables separate from cables with voltages >60V.
• Use cables with twisted wires.
• Keep device and cables at a distance from strong electromagnetic 󹪝elds.
• Take account of the conditions for communication speci󹪝ed in the Technical speci󹪝cations
(Page169).
Note
Conduit seals
Use appropriate conduit seals to maintain applicable IP and NEMA ratings.
Note
DC in
put terminals
The DC input terminals shall be supplied from a source providing electrical isolation between the
input and output, in order to meet the applicable safety requirements of IEC 61010-1. For
example, SELV source.
Note
All 󹪝eld wir
ing must have insulation suitable for rated voltages.
6.2 Connecting SITRANS LR500 series
6.2.1
Wiring instructions
Note
Initial connection when displa
y ordered separately from the device
Only follow the display wiring instructions if the display is ordered separately from the device.
The display is connected when ordered at the same time as the device.
1. To remove lid from the device, turn by hand in a counter-clockwise direction.
2. Strip cable jacket for approximately 70 mm (2.75 inch) from end of cable, and thread wires
through gland.
Connecting
6.2Connecting SITRANS LR500 series
SITRANS LR500 series with mA/HART
52 Operating Instructions, 03/2024, A5E51099898-AA
