7.6.5 Requesting an echo pr
ole
Procedure
After commissioning the device, an echo prole may be viewed on the HMI or using a remote
engineering system, such as SIMATIC PDM.
For details, see SIMATIC PDM (Page207).
① X-axis: Distance
Dis
tance units can be set to: m, cm,
mm, ft, in.
⑤ Algorithm used
2)
② Y-axis: Echo amplitude (in dB) ⑥ Echo
③ Distance from sensor face to target ⑦ TVT
3)
④ Echo condence
1)
1)
See Condence (P
age202)
2)
See Auto false echo suppression and Custom TVT (Page202)
3)
Where AFES has been learned, AFES curve replaces TVT curve (see Auto false echo suppression
(Page98) ).
1. In measurement view, press
to navigate to parameter view Maint. and diag.
Diagnos
tics
Ec
ho prole (3.2.1) (Page130).
2. Press
to start wizard and request a pr
ole.
3. To update to current prole, press
and
4
. To exit and return to the previous menu, press
button.
7.6.6
Device address
Setting a device address is not necessary for local operation, but must be set if conguring the
device for use on a HART network. See Polling address (4.1) (Page145).
Commissioning
7.6Local commissioning
SITRANS LR500 series with mA/HART
Operating Instructions, 03/2024, A5E51099898-AA 83
