Description
4
4.1 Description
SITRANS
LR500 series radar level transmitter with HART, 4 to 20 mA is ideal for level and volume
measurements. It is suitable for liquids, slurries, and bulk solids.
LR510 threaded lens antenna
î™
LR530 󹪞ang
ed encapsulated antenna
LR550 polymeric horn antenna
LR580 󹪞ang
ed lens antenna
î™
A thermal extension part is supplied between the housing and the process connection,
yielding e
xtended process temperature capability. See image below of LR510 with extension
as a reference.
4.2 Applications
SITRANS LR500 ser
ies is a 80 GHz advanced radar level device designed to measure liquids,
slurries and solids in a variety of applications:
SITRANS LR500 series with mA/HART
Operating Instructions, 03/2024, A5E51099898-AA 31
