12.4 Interface
HART 7 Standard, integral to analog output
Con󹪝guration Local graphical display with backlight and pushbuttons. SITRANS mobile
IQ
App with AW050 module (non Ex devices only), Siemens SIMATIC PDM
HMI (local)
1)
Graphical backlit liquid crystal, with bar graph (representing Level)
1)
Displa
y will be degraded below -25 °C (-13 °F) and above 65 °C (149 °F)
12.5 Outputs
Analog output
 4 to 20 mA (3.8 min. to 20.5 max. adjustable)
800 ohms max.
Deviation in the current output due to digital/analogue conversion < +/-10 µA
1)
A
dditional deviation through electromagnetic interference:
• According to EN 61326-1: none
• According to EN61000-6-2: < +/-20 µA
• According to NAMUR NE 21: < +/-20 µA
Resolution of <1 μA
Non-repeatability of <1 μA
Startup behaviour: 3.6mA, < 25 seconds
In󹪞uence of ambient t
emperature: 0.02% / 10K
1)
A
dd error of the digital value to the analog value.
12.6 Construction
Enclosure Body material aluminum with polyurethane powder
coat
Ingress protection
• IP66, TYPE 4X
• IP68 (2 meters, 24 hours), TYPE 6
Materials
LR510 (t
hreaded connection) Options
 Sealing material of the antenna/process connec‐
tion
PEEK/FKM
PEEK/FFKM
Kling
ersil 󹪞at seal for G thread versions
Process connection material 316/316L
Allo
y C22 (2.4602)
LR530 (󹪞ang
ed encapsulated PTFE antenna)
Technical speci󹪝cations
12.6Construction
SITRANS LR500 series with mA/HART
172 Operating Instructions, 03/2024, A5E51099898-AA
