Page #112 background imageLoading...
Page #112 background image
10.12 Boundaries
Click the Tool Boundary entry to configure the orientation boundary limit for the robot tool. The
configuration of the limit can be specified in the Tool Boundary Properties section (see 10.12.4)
at the bottom of the tab.
Click the / button to toggle the 3D visualization of the boundary limit on/off. If a boundary
limit is active, the safety mode (see 10.12.3 and 10.12.4) is indicated by one of the following icons
/ / / .
10.12.2 3D visualization
The 3D View displays the configured safety planes and the orientation boundary limit for the
robot tool together with the current position of the robot arm. All configured boundary entries
where the visibility toggle is selected (i.e. showing icon) in the Safety Boundaries section
are displayed together with the current selected boundary limit.
The (active) safety planes are shown in yellow and black with a small arrow representing the plane
normal, which indicates the side of the plane on which the robot TCP is allowed to be positioned.
Trigger planes are displayed in blue and green. A small arrow illustrates the side of the plane that
does not trigger the transition into Reduced mode. If a safety plane has been selected in the panel on
the left side of the tab, the corresponding 3D representation is highlighted.
The tool orientation boundary limit is visualized with a spherical cone together with a vector indi-
cating the current orientation of the robot tool. The inside of the cone represents the allowed area
for the tool orientation (vector).
When a plane or the tool orientation boundary limit is configured but not active, the visualization
is gray.
Push the magnifying glass icons to zoom in/out or drag a finger across to change the view.
10.12.3 Safety plane configuration
The Safety Plane Properties section at the bottom of the tab defines the configuration of the
selected safety plane in the Safety Boundaries panel in the upper left portion of the tab.
CB3 II-14 Version 3.10
Copyright © 2009–2019 by Universal Robots A/S. All rights reserved.
