3 Transportation
Transport the robot in the original packaging. Save the packaging material in a dry place; you may
need to pack down and move the robot later on.
Lift both tubes of the robot arm at the same time when moving it from the packaging to the instal-
lation place. Hold the robot in place until all mounting bolts are securely tightened at the base of
the robot.
The controller box shall be lifted by the handle.
WARNING:
1. Make sure not to overload your back or other bodyparts when
the equipment is lifted. Use proper lifting equipment. All
regional and national guidelines for lifting shall be followed.
Universal Robots cannot be held responsible for any damage
caused by transportation of the equipment.
2. Make sure to mount the robot according to the mounting in-
structions in chapter 4.
Version 3.10
Copyright © 2009–2019 by Universal Robots A/S. All rights reserved.
I-21 UR3/CB3
