– If necessary let the excess oil flow out until it only drips.
The oil level is correct when the oil drips out of the oil filler hole.
– Install a new oil filter plug -arrow- with a permanent seal and
tighten to the tightening specification.
Tightening Specification Nm
Oil filler plug 15
Check the specified temperature range while checking the oil lev‐
el, if while filling an oil temperature between 20° to 40 °C (68 to
104 °F) cannot be guaranteed.
The oil temperature can be measured using the Digital Thermom‐
eter - VAS6519- .
If the oil temperature is not between 20° to 40 °C (68 to 104 °F),
either drive the vehicle to warm it up or let the oil temperature cool
down.
Oil Capacities and Oil Specifications
4MOTION oil ca‐
pacity
Refer to ⇒ Fluid Capacity Tables; Rep. Gr. 03 .
Oil specification Refer to ⇒ Fluid Capacity Tables; Rep. Gr. 03
4.29 High-Voltage Battery Charge Level,
Checking
Note
Only applies to e-Golf.
Checking Charge Level:
The high-voltage battery charge level indicator is located in the
right at the bottom of the instrument cluster.
First record the charge level at vehicle delivery:
Golf 2013 ➤ , Golf Sportsvan 2015 ➤ , Golf Variant 2014 ➤ , e-Golf 2014 ...
Maintenance - Edition 06.2015
102 4. Procedure Descriptions
To Next Page
