Tightening Specification Nm
Screws for air filter upper section and air filter lower
section -1-
1.5
Air filter housing bolt -2- 5
4.40.6 Air Filter Element, Removing and Instal‐
ling, 1.6L SRE Engine
Removing
– Remove the air guide hose -1- from the air filter upper section.
– Remove bolts -arrows- from the air filter housing upper sec‐
tion.
– Disengage the air filter upper section -3- with the entire air
guide to the side.
– Remove the air filter -2-
Installing
– Check the housing and the water drains for dirt and clean them
if necessary.
– Insert the air filter -2- centrally in the mount on the air filter
housing lower section.
– Carefully place the air filter upper section -3- without great
force onto the air filter lower section. Install and tighten the
screws to specification.
– Install the air guide hose -1- on the air filter upper section.
Tightening Specification Nm
Bolts 2
4.41 Multipurpose Additive for Gasoline,
Adding
Note
♦
Only applies to China, Russia, and India.
♦
Use only additives that meet the standard VW 507 53 A or VW
507 53 B.
♦
Pay attention to the dosing instructions on the additive tank.
♦
For maximum effectiveness, recommend to the customer after
adding the additive to completely fill up the fuel tank.
– Add multipurpose additive for gasoline to the regular fuel tank
at every service.
Golf 2013 ➤ , Golf Sportsvan 2015 ➤ , Golf Variant 2014 ➤ , e-Golf 2014 ...
Maintenance - Edition 06.2015
4. Procedure Descriptions 125
