Adjusting screws for the right headlamp are a mirror image.
♦ Adjusting screw (inner hex socket) for height adjustment of low
beam cut-off line -1-.
♦ Adjusting screw (inner hex socket) for lateral adjustment of low
beam cut-off line -2- (sealed on NAR vehicles)
– First turn adjustment screw -1- to adjust height of cut-off line.
– Then the lateral adjustment must be checked and, if neces‐
sary, correct using the adjusting screw -2-.
4.56.4 Headlamp Adjustment, Checking (ECE)
Special tools and workshop equipment required
♦ Headlamp Adjusting Unit - VAS5046A-
♦ Headlamp Adjusting Unit - VAS5047A-
♦ Headlamp Adjuster - VAS5208A-
Note
For certain markets, no manual headlamp range control is offered
with halogen headlamps.
– Check the headlamp height adjustment by setting to the max‐
imum level and observing the light.
– Then set the thumbwheel for the headlamp range control to
the 0 position, if equipped.
The adjustment of the angle dimension on headlamp adjusting
unit is based on the fuel tank fill level.
Angle dimension for halogen headlamp (ECE)
Fuel gauge
level
Angle dimension
0 to 1/2 1.2 %
1/2 to 1 1.0 %
Check the following:
Golf 2013 ➤ , Golf Sportsvan 2015 ➤ , Golf Variant 2014 ➤ , e-Golf 2014 ...
Maintenance - Edition 06.2015
160 4. Procedure Descriptions
