Caution
Follow the points below to avoid running the high pressure
pump dry (very low tolerances) and to start the engine quickly
after replacing the components:
♦ If fuel system components between the fuel tank and high
pressure fuel pump are removed or replaced, then the fuel
system must be filled/bleed before the first engine start.
Bleeding the Fuel System:
• The vehicle must be fueled.
ODIS Service
– Connect the Vehicle Diagnostic Tester . Refer to ⇒ “3.5 Vehicle Diagnostic Tester ”, page 14 .
– Switch on the ignition.
– Perform the vehicle identification.
– Enter the work order data or select “no work order”.
– Select “control module”.
– Select “engine electronics”.
– Select “Guided Functions”.
– Select “fuel pump activation”.
– Follow the “Guided Functions” instructions.
– Start the engine after bleeding the fuel system.
– Let the engine idle for a few minutes and then turn it off again.
– Check the DTC memory and delete it if necessary.
– Perform a leak test on the fuel system.
Note
If there still is air in the fuel system, the engine may go into the
emergency running mode during the road test. In this case turn
off the engine and delete the DTC memory. Then continue the
road test.
4.40 Air Filter, Cleaning Housing and Replac‐
ing Filter Element
⇒ “4.40.1 Air Filter Element, Removing and Installing, 1.4L TSI
Engines”, page 117 .
⇒ “4.40.2 Air Filter Element, Removing and Installing, 2.0L TSI
Engine”, page 119 .
⇒ “4.40.3 Air Filter Element, Removing and Installing, Common
Rail Engines ”, page 121 .
Special tools and workshop equipment required
Golf 2013 ➤ , Golf Sportsvan 2015 ➤ , Golf Variant 2014 ➤ , e-Golf 2014 ...
Maintenance - Edition 06.2015
116 4. Procedure Descriptions
