♦ Left Front Lock Carrier
♦ High-Voltage Battery Charger 1 - AX4-
♦ Electric Drive Power and Control Electronics - JX1-
♦ Three-Phrase Current Drive - VX54- - side
♦ Three-Phrase Current Drive - VX54- - below
♦ Electrical A/C Compressor - V470-
♦ High-Voltage Heater (PTC) - Z115-
♦ High-Voltage Battery 1 - AX2- - side
♦ High-Voltage Battery 1 - AX2- - top
4.72 Camshaft Drive Toothed Belt, Replac‐
ing, Diesel Engines
TDI CR engines:
– Refer to ⇒ Engine Mechanical, Fuel Injection and Ignition;
Rep. Gr. 15 ; Toothed Belt Drive; Toothed Belt Removing,
Installing .
Golf 2013 ➤ , Golf Sportsvan 2015 ➤ , Golf Variant 2014 ➤ , e-Golf 2014 ...
Maintenance - Edition 06.2015
4. Procedure Descriptions 201
