♦ The high-voltage components must not show any damage on
the outside.
♦ The insulation on the high-voltage cables must be intact with‐
out any damage.
♦ Look for any unusual deformations on the high-voltage cables.
Note
Inform the high-voltage technician if something seems wrong or
missing.
4.34 Interior and Exterior Body, Visually In‐
specting for Corrosion with Doors and
Lids Opened
Test Locations
♦ Sunroof frame
♦ Inner and outer door frame
♦ The area around the trim moldings
♦ Windshield roof edge
♦ Outer and inner A-pillar
♦ Hood
♦ Wheel housings
♦ Inner and outer rear lid
4.35 Ribbed Belt, Checking Condition
Perform the Following Procedure:
– Turn engine at vibration damper/ belt pulley with socket
wrench.
Golf 2013 ➤ , Golf Sportsvan 2015 ➤ , Golf Variant 2014 ➤ , e-Golf 2014 ...
Maintenance - Edition 06.2015
4. Procedure Descriptions 105
