The oil temperature can be measured using the Digital Thermom‐
eter - VAS6519- .
If the oil temperature is not between 20 to 40 °C (68 to 104 °F),
either drive the vehicle to warm it up or let the oil temperature cool
down.
Oil Capacities and Oil Specifications
Front axle-differential lock oil
capacity GTI
Refer to ⇒ Fluid Capacity Tables; Rep. Gr. 03 .
Oil specification Refer to ⇒ Fluid Capacity Tables; Rep. Gr. 03 .
4.69.1 Front Axle Differential Lock, Changing
Oil, “R Model”
Note
The front axle oil in the bevel box must only be drained for repair.
An oil change is not possible.
Special tools and workshop equipment required
♦ Charging Device For Haldex Coupling 2 - VAS6291A-
♦ Charging Device For Haldex Coupling 2 - Adapter 3 -
VAS6291/3-
Golf 2013 ➤ , Golf Sportsvan 2015 ➤ , Golf Variant 2014 ➤ , e-Golf 2014 ...
Maintenance - Edition 06.2015
188 4. Procedure Descriptions
