“At the min mark and slightly above it” -2-, “NO TOPPING OFF
REQUIRED”.
• Recommended brake fluid level when brake pads are new or
are far removed from the brake pad wear limit:
“Between the min and max marks”.
WARNING
If the fluid level goes below the min mark -2-, check brake sys‐
tem for leaks before adding more brake fluid. Refer to the
“repair procedure”.
4.13 6-Speed Direct Shift Gearbox (DSG®)
Transmission 0D9, Changing Transmis‐
sion Fluid and Filter
Procedure
Refer to ⇒ DSG Transmission; Rep. Gr. 34 ; Transmission Fluid;
Transmission Fluid, Draining and Filling .
Refer to ⇒ DSG Transmission; Rep. Gr. 34 ; Transmission Fluid
Circuit; Transmission Fluid Filter, Removing and Installing .
4.14 6-Speed Direct Shift Gearbox (DSG®)
Transmission 0DD, Changing Trans‐
mission Fluid
Procedure
Refer to ⇒ DSG Transmission; Rep. Gr. 34 ; Transmission Fluid;
Transmission Fluid, Draining and Filling .
4.15 Diesel Parcticulate Filter, Checking
Note
If the displays indicated in the procedure are not shown on the
display. Refer to the Vehicle Diagnostic Tester Operating Instruc‐
tions.
ODIS Service
– Connect the Vehicle Diagnostic Tester . Refer to ⇒ “3.5 Vehicle Diagnostic Tester ”, page 14 .
– Switch on the ignition.
– Perform the vehicle identification.
– Enter the work order data or select “no work order”.
– Select “control module”.
– Select “engine electronics”.
– Select “Guided Functions”.
– Select “check particulate filter ash load value”.
– Follow the “Guided Functions” instructions.
