– With the low beam switched on, check whether the horizontal
cut-off line contacts the test surface dividing line -1- and
– If the bend point -2- runs vertically through the central point
-3- between the left horizontal part and the rising part on the
right of the cut-off line. The bright core of the light beam must
be on the right of the vertical line.
Note
After adjusting the low beam according to the instructions, the
center of the high beam light beam must lie on the center mark
-3-.
4.57 Headlamp Adjustment, Checking, HID
Headlamp without Dynamic Light Assist
⇒ “4.57.1 Checking and Adjusting Conditions”, page 161 .
⇒ “4.57.2 Headlamp Adjustment, Checking (SAE)”, page 162 .
⇒ “4.57.3 HID Headlamps without Dynamic Light Assist, Adjust‐
ing”, page 163 .
Note
♦ The use of additional weight is discontinued.
♦ For that reason, different angle dimension settings are used
on the headlamp adjusting unit.
♦ When using the maintenance tables, the adjustment values
are also shown in the vehicle-specific maintenance list.
♦ In the US and Canadian markets, headlamps with SAE ap‐
proval are used in vehicles.
♦ Adjusting the headlamps is invoiced separately.
4.57.1 Checking and Adjusting Conditions
• Tire pressure OK
• The headlamp glass must not be damaged or dirty.
• Reflectors and light sources OK
• Initialization phase of the headlamp range control must be
completed.
1)
• Move vehicle back and forth for a few meters or bounce the
front and rear of vehicle several times up and down to settle
the springs.
• The vehicle and the headlamp adjusting unit must be on level
ground.
• Vehicle or headlamp adjusting unit must be aligned.
• Angle dimension must be set.
• The DTC memory must be erased.
• The headlamp adjusting unit if equipped must be located in
the correct adjustment mode.
• Pay attention to the Headlamp Adjusting Unit Owner's Manual.
1)
A referencing operation occurs for the headlamp range control
stepper motors in the dimming direction during the initialization
Golf 2013 ➤ , Golf Sportsvan 2015 ➤ , Golf Variant 2014 ➤ , e-Golf 2014 ...
Maintenance - Edition 06.2015
4. Procedure Descriptions 161
