of the cut-off line. The bright core of the light beam must be on
the right of the vertical line.
– Switch on the high beam.
– Adjust the angle dimension on the Headlamp Adjusting Unit to
“0 %”.
– Turn the high beam height adjustment adjusting screw -1-,
until the center of the high beam light beam lies on the center
mark. Refer to Test Diagram for Low Beam ⇒ page 173 -3-.
Assembly of the headlamp is done in the reverse order.
4.60 Headlamp Adjustment, Checking, Fog
Lamp
⇒ “4.60.1 Checking and Adjusting Conditions”, page 176 .
⇒ “4.60.2 Headlamps, Checking Adjustment”, page 176 .
⇒ “4.60.3 Fog Lamps and Other Auxiliary Headlamps, Adjusting”,
page 177 .
Note
♦
The use of additional weight is discontinued.
♦
For that reason, different angle dimension settings are used
on the headlamp adjusting unit.
♦
When using the maintenance tables, the adjustment values
are also shown in the vehicle-specific maintenance list.
♦
Adjusting the headlamps is invoiced separately.
4.60.1 Checking and Adjusting Conditions
• Tire pressure OK
• Cover lenses must not be damaged or dirty.
• Reflectors and bulbs OK
• Move vehicle back and forth for a few meters or bounce the
front and rear of vehicle several times up and down to settle
the springs.
• The vehicle and the headlamp adjusting unit must be on level
ground.
• Vehicle and headlamp adjusting unit must be aligned.
• Angle dimension must be set.
• Pay attention to the Headlamp Adjusting Unit Owner's Manual.
4.60.2 Headlamps, Checking Adjustment
Special tools and workshop equipment required
♦ Headlamp Adjusting Unit - VAS5046A-
♦ Headlamp Adjusting Unit - VAS5047A-
♦ Headlamp Adjuster - VAS5208A-
The adjustment of the angle dimension on headlamp adjusting
unit is based on the fuel tank fill level.
Golf 2013 ➤ , Golf Sportsvan 2015 ➤ , Golf Variant 2014 ➤ , e-Golf 2014 ...
Maintenance - Edition 06.2015
176 4. Procedure Descriptions
