4.23 Driving School Pedals, Lubricating
Components
⇒ “4.23.1 General Information”, page 89
⇒ “4.23.2 Brake Carrier Slot Lever, Lubricating, Driver Side Driv‐
ing School Pedals”, page 89
⇒ “4.23.3 Accelerator Pedal Carrier Slot Lever, Lubricating, Driver
Side Driving School Pedals”, page 90
⇒ “4.23.4 Brake Transfer Push Rod Joint, Lubricating, Driver Side
Driving School Pedals”, page 90
⇒ “4.23.5 Right Shaft Bearing, Lubricating, Driver Side Driving
School Pedals”, page 91
⇒ “4.23.6 Left Shaft Bearing, Lubricating, Driver Side Driving
School Pedals”, page 91
⇒ “4.23.7 Left Shaft Bearing, Lubricating, Front Passenger Side
Driving School Pedals”, page 92
⇒ “4.23.8 Right Shaft Bearing, Lubricating, Front Passenger Side
Driving School Pedals”, page 92
4.23.1 General Information
This is performed at every service procedure.
Additional information in “Operating Dual Controls” this is located
with the vehicle. The Owner's Manual is included with the driving
school pedals. The Owner's Manual and the general type appro‐
val must always be available in the vehicle.
The procedure for the service work is the same for manual trans‐
mission and automatic transmission vehicles.
Caution
The tension on the driving school pedals spring must never be
retightened as there is a risk of breakage.
Wipe all of the moveable parts on the sticky driving school
pedals using the Universal Towel - VAS6385- or a lint-free,
untouched cloth and lubricate them again with the Special Lu‐
bricant - G 052 172 A2- .
For defects with the driving school pedals, please contact the
Volkswagen dealer center with replacement part requests. Addi‐
tional information is available on Volkswagen ServiceNet.
Driving School Pedals, Checking for Bolt Secure Fit. Refer to
⇒ “4.24 Driving School Pedals, Checking for Secure Bolt Fit”,
page 93 .
Activation timing for the control equipment warning buzzer, ad‐
justing. Refer to
⇒ “4.26 Driving School Pedals, Adjusting Activation Timing for
Control Equipment Warning Buzzer”, page 97 .
4.23.2 Brake Carrier Slot Lever, Lubricating,
Driver Side Driving School Pedals
Special tools and workshop equipment required
♦ Universal Towel - VAS6385-
♦ Lint-free cleaning towel
Golf 2013 ➤ , Golf Sportsvan 2015 ➤ , Golf Variant 2014 ➤ , e-Golf 2014 ...
Maintenance - Edition 06.2015
4. Procedure Descriptions 89
