3 General Information
⇒ “3.1 High-Voltage System General Warnings”, page 12 .
⇒ “3.2 Vehicle, Raising with Hoist or Workshop Vehicle Jack”,
page 12 .
⇒ “3.3 Label”, page 14 .
⇒ “3.4 Maintenance Schedule Entries”, page 14 .
⇒ “3.8 Severe Operating Conditions”, page 17 .
⇒ “3.5 Vehicle Diagnostic Tester ”, page 14 .
⇒ “3.6 Vehicle Identification Number (VIN)”, page 15 .
⇒ “3.7 Vehicle Data Label”, page 16 .
⇒ “3.9 Country Assignment According to Market Designation”,
page 17 .
⇒ “3.10 Engine Code and Engine Number”, page 17 .
⇒ “3.12 Type Plate”, page 18 .
3.1 High-Voltage System General Warnings
Refer to ⇒ Electric Drive; Rep. Gr. 00 ; High Voltage System
Danger Classification .
3.2 Vehicle, Raising with Hoist or Workshop
Vehicle Jack
⇒ “3.2.1 Safety Precautions”, page 12 .
⇒ “3.2.2 Hoist and Floor Jack Mounting Points”, page 13
3.2.1 Safety Precautions
WARNING
♦ Before driving the vehicle onto a workshop hoist, make
sure there is enough clearance between any low-lying
components and the hoist.
♦ Before driving a vehicle onto a hoist it must be ensured
that the vehicle weight does not exceed the permitted load
rating of the platform.
♦ Vehicle may only be lifted at points indicated in illustration
in order to avoid damaging vehicle floor pan and to prevent
vehicle from tipping.
♦ Never start engine and engage a gear with vehicle lifted
so long as even one wheel has contact with the floor!
There is a risk of an accident if this is not observed!
♦ If work is to be performed under vehicle it must be sup‐
ported by suitable stands.
Golf 2013 ➤ , Golf Sportsvan 2015 ➤ , Golf Variant 2014 ➤ , e-Golf 2014 ...
Maintenance - Edition 06.2015
12 3. General Information
To Next Page
