Xerox WorkCentre 5230A User Manual

149
7 CentreWare Internet Services
The CentreWare Internet Services program uses the embedded web user interface
which enables communication between a networked computer and the machine via
HTTP. CentreWare Internet Services can be used to check the machine status and the
status of each job, and to change the machine configuration.
This chapter explains how to enable and use CentreWare Internet Services for the
machine. The following information is provided:
Information Checklist – page 149
CentreWare Internet Services Environments – page 150
CentreWare Internet Services Installation – page 150
Installation Procedure – page 150
Network Communication Setup – page 150
Test Access – page 152
Selecting Transport Protocols – page 153
Screen Layout – page 153
Services – page 154
Status – page 156
Jobs – page 158
Print – page 160
Scan – page 162
Properties – page 178
Support – page 230
NOTE: For troubleshooting CentreWare Internet Services, refer to CentreWare
Internet Services in the Problem Solving chapter on page 383
.
Information Checklist
Before enabling the CentreWare Internet Services feature, make sure that the following
items are available or have been performed.
Item By
An existing operational computer with TCP/IP Internet or intranet
accessibility is required. These procedures are not intended to install
the TCP/IP stack itself.
Customer
Obtain and record the following information:
• A Unique IP Address
• Gateway Address
• Subnet Mask (for IPv4) / Prefix (for IPv6)
Customer
Test the machine to make sure that it is fully installed and functioning
correctly.
Customer

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
