Xerox WorkCentre 5230A User Manual

10 Scanner Environment Settings
284
Scanning Process
The machine has five types of scanning functions.
• Scan to E-mail
• Scan to Mailbox
• Network Scanning
• Scan to PC (FTP)
• Scan to PC (SMB)
The setup procedures are as follows.
Scan to E-mail Setup
Hard copies can be scanned at the machine and sent to remote clients as e-mail
attachments in Single TIFF, Multi TIFF, PDF, PDF/A*, JPEG*, or XPS format. SMTP
and POP3 mail servers are used to send and receive e-mail respectively.
*: The PDF/A and JPEG file formats are supported by the WorkCentre 5225A/5230A
only.
NOTE: XPS stands for XML Paper Specification.
Prerequisites for Scan to E-mail Setup
1. Confirm that an existing operational network using TCP/IP is available.
2. Confirm that DNS and the Domain Name have been correctly setup for the
multifunction machine.
3. Confirm that the following ports are enabled:
• Scan to E-mail: [Send E-mail]
• E-mail Print: [Receive E-mail]
• E-mail Notification Service/Notify Job End by E-mail: [E-mail Notification
Service]
Data to Set Up E-mail Install
Requirement
Comments
SMTP mail server Host Name or IP
address
Required If using an external mail server, your
Internet Service Provider will provide you
with the mail server name or IP address.
SMTP login/password Required*
WorkCentre E-mail address Required
Local e-mail addresses Optional A Local Address Book can be created to
store e-mail addresses.
LDAP server address can be
enabled
LDAP Host Name Displays only e-mail addresses on the
corporate (LDAP) internal address book.
* Only if the SMTP server requires login and password for authentication.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
