Xerox WorkCentre 5230A User Manual

Properties
179
Properties Features
The following table lists the items that can be set.
Some items may not be displayed depending on your machine configuration.
Feature Setting items
Configuration Overview Connectivity and Printing
Print Protocols – Clicking the [Settings] button displays
the [Connectivity and Printing] page, which displays
links to the following property settings pages. Some
items may not appear depending on your machine
configuration.
• EtherTalk – Clicking the [Configure] button displays
the [EtherTalk Compatible System] page. For details
on the page, refer to
EtherTalk on page 188 .
• NetWare – Clicking the [Configure] button displays
the [NetWare] page. For details on the page, refer to
NetWare on page 188 .
• TCP/IP – Clicking the [Configure] button displays the
[TCP/IP] page. For details on the page, refer to
TCP/IP on page 190 .
• Microsoft Networking – Clicking the [Configure]
button displays the [Microsoft Networking] page. For
details on the page, refer to
Microsoft Networking on
page 194
.
• LPD – Clicking the [Configure] button displays the
[LPD] page. For details on the page, refer to
LPD on
page 195
.
• Port 9100 – Clicking the [Configure] button displays
the [Port 9100] page. For details on the page, refer
to
Port 9100 on page 195 .
• HTTP – Clicking the [Configure] button displays the
[HTTP] page. For details on the page, refer to
HTTP
on page 198
.
Services
Clicking the [Settings] button for each service displays
a configuration page, which displays links to various
setting pages. Fill out the setting pages to set up each
service. To display the configuration page for the next
service, click the [Configure Next Service] button.
Some items may not appear depending on your
machine configuration.
E-mail Settings:
• SMTP Server – Clicking the [Configure] button
displays the [SMTP Server] page. For details on the
page, refer to
SMTP Server on page 196 .
• LDAP Directory – Clicking the [Configure] button
displays the [LDAP Server] page. For details on the
page, refer to
LDAP Server on page 196 .

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
