Xerox WorkCentre 5230A User Manual

UNIX TCP/IP
251
• -
You can delete all your print data by specifying this option. If this option is issued by
a superuser, all the print data received by the machine will be deleted.
This option is only valid in the spool mode.
NOTE: Print data which consist of multiple files sent in one print instruction cannot be
deleted file by file. All the files will be deleted together.
NOTE: This command is invalid if no options are specified, or if there is no print data
which matches the option.
NOTE: You can delete only print data from the same workstation used to send the
print data. You cannot delete print data sent by other workstations.
NOTE: When a command to delete print data is received, the file will be deleted even
if it is in the process of being printed. Any unprinted data will be cancelled after the file
has been deleted.
Example
To delete the print data from printer fxPS for job number 351, enter the following
command:
%lprm -PfxPS 351
Printer Status
Solaris/HP-UX
The lpstat command is used to inquire about the status of the machine.
NOTE: In the non-spool mode, this function is available to Windows NT clients but not
to HP-UX/Solaris clients.
Command format
lpstat [option]
Command options
The following command options are available.
If no option is specified, all the print data-related information will be displayed.
The sequence of the options does not affect the outcome.
To use more than one argument at the same time, separate them by commas and
enclose all the arguments with “ ”.
E.g. %lpstat -u "user1,user2,user3"
• -o [printer name]
This option displays the print data for the specified printer.
•-t
This option displays all the information.
• -u [user name]
This option displays information about print data received from specified users.
• -v [printer name]
This option displays the printer name and the path name for the machine. The printer
name is specified in the argument.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
