Xerox WorkCentre 5230A User Manual

6Setups
96
• POP Password Encryption
Specifies whether to enable the POP password encryption using APOP.
SMTP Server Settings
Specifies the SMTP server settings. Use the scroll buttons to switch between screens.
• SMTP Server Name / IP Address
Specifies the domain name or IP address of the SMTP server.
• SMTP Server Port Number
Specifies the SMTP server port number.
• E-mail Send Authentication
Specifies the SMTP server authentication method. If you select [POP before SMTP],
POP server authentication is required before transmitting e-mails to the SMTP
server. If you select [SMTP AUTH], the SMTP server authentication is enabled.
• SMTP AUTH Login Name
Specifies the SMTP AUTH login name. Enter a login name of up to 64 characters.
This entry is required only when [SMTP AUTH] is selected on the [E-mail Send
Authentication] screen.
• SMTP AUTH Password
Specifies the SMTP AUTH password. Enter a password of up to 36 characters and
then re-enter the password for confirmation. This entry is required only when [SMTP
AUTH] is selected on the [E-mail Send Authentication] screen.
Domain Filtering
Specifies domain name restrictions to filter incoming e-mail.
• Domain Filtering
Specifies whether to enable domain filtering, and the type of filtering. Select from
[Allow Domains] and [Block Domains] to enable filtering.
• Domain 1 to 50
Specifies the domain names to be restricted or permitted according to the selection
on the [Domain Filtering] screen.
Remote Authentication Server Settings
This feature allows you to set up the external authentication server and directory
service settings. The options available may vary depending on your machine
configuration.
1. Select [Remote Authentication
Server Settings] in the
[Features] menu.
2. Change the required settings.
3. Select [Close].
Authentication System Setup
• Authentication System
Specifies the remote authentication service. Select from [Kerberos (Windows
2000)], [Kerberos (Solaris)], [LDAP], [SMB], and [Authentication Agent].

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
