4 Job Status
44
Private Charge Print
The Private Charge Print feature temporarily stores documents per user ID, until a user
logs in and manually prints them from the machine’s control panel. This feature only
displays documents of a logged-in user, and thus provides security and privacy to
documents stored in the machine.
NOTE: This feature is displayed only when [System Settings] > [Authentication/
Security Settings] > [Authentication] > [Charge/Private Print Settings] > [Receive
Control] > [Save in Private Charge Print] is selected.
1. Press the <Log In/Out> button.
2. Enter your user ID using the screen board or numeric keypad on the control panel,
and select [Confirm].
3. Select [Private Charge Print] on the [Secure Print Jobs & More] screen.
NOTE: If you log in to the machine
with the System Administrator’s ID,
a list of user login IDs is displayed
on the screen. Select the desired
user ID from the list or enter it in [Go
to], and select [Document List]. The
documents stored for the selected user ID will be displayed.
4. Select a document to print or
delete.
5. Select the required option.
Refresh
Refreshes the displayed information.
Select All
Selects all documents in the list.
Delete
Deletes a document selected in the list.
Print
Prints a document selected in the list. After printing, the document will be deleted.
Secure Print
This feature allows you to print or delete passcode-protected stored documents. A
secure print job requires a user ID and a passcode registered in the machine.
1. Select [Secure Print] on the
[Secure Print Jobs & More]
screen.
2. Select a user ID.
NOTE: Use the scroll buttons to
switch between screens.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
