Xerox WorkCentre 5230A User Manual

14 Authentication and Account Administration
342
6. Enter the domain in the [Domain Name] box. For example: example.com
7. Enter details for up to four alternate servers and backups, if required.
8. Click [Apply].
Configuring Remote Authentication for SMB
At Your Workstation:
1. Click the [Properties] tab.
2. Expand the [Security] folder, and then the [Remote Authentication Servers] folder.
3. Click [SMB Server].
4. From the [SMB Server Setup] drop-down menu, select your desired method.
5. Enter the domain name (up to 64 characters) in the [Domain Name] box. This
setting is mandatory.
6. Enter the IP Address of the domain controller in the [Server Name/IP Address]
box (if [By Domain Name and Server Address / IP Address] was selected for
[SMB Server Setup]).
7. Repeat steps 7 and 8 for the configuration of up to four additional backup domain
controllers, if applicable.
8. Click [Apply].
Configuring Remote Authentication for LDAP
Refer to your LDAP server documentation for the full range of information that can be
entered into this LDAP dialog to fully support both e-mail applications and
authentication using your LDAP server.
The path to the LDAP dialog is as follows:
At Your Workstation:
1. Click the [Properties] tab.
2. Expand the [Connectivity] folder, the [Protocols] folder, and then the [LDAP] folder.
3. Click [LDAP Server].
4. Under [Server Information], enter the IP address (or host name) in the box
supplied.
NOTE: If entering a fully qualified host name (for example, ldapserver.xerox.com),
make sure that the specified domain name matches the machine’s TCP/IP
configuration (domain name shown under DNS on the machine’s Configuration
Report).
5. Enter the port number (default of 389).
6. If available, decide whether or not to use encryption (Authentication with SSL)
when accessing the LDAP server.
7. Specify the LDAP server environment from the [LDAP Server] drop-down list.
8. If required, enter the path to the LDAP objects to limit the LDAP search in the
[Search Directory Root] field. The entry should be in base DN format (for instance,
ou=people, dc=xerox, dc=com).

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
