Xerox WorkCentre 5230A User Manual

14 Authentication and Account Administration
318
Feature Access
• Print Documents from Mailbox
• Retrieve Documents from Mailbox
Remote Access
Operation of the machine through a network using CentreWare Internet Services is
called Remote Access.
The functions restricted by Remote Access are as follows.
Print
Printing is limited to print jobs sent from a computer.
To use the Accounting feature, use the print driver to set account information such as
user ID and passcode.
If verification using account information fails for a print job, the print data will be either
saved in the machine or deleted depending on the Charge Print settings.
NOTE: Printing is not limited when [Login Type] is set to [Login to Remote Accounts]
in the System Administration mode. For more information about [Login to Remote
Accounts], refer to
Login Type on page 141 .
Direct Fax
Direct Fax from a computer is restricted.
To use the Authentication feature, use the fax driver to set authentication information
such as user ID and passcode.
The fax jobs sent to the machine that fail authentication are set to Charge Print and are
either saved to the machine or deleted, depending on the selected setup option.
NOTE: Direct Fax is not restricted when [Login Type] is set to [Login to Remote
Accounts] in the System Administration mode. For more information about [Login to
Remote Accounts], refer to
Login Type on page 141 .
CentreWare Internet Services
If the Authentication feature is enabled, authentication is required to access the
CentreWare Internet Services home page even if you are not using the Authentication
feature for any service.
NOTE: Only the System Administrator is allowed access when [Login Type] is set to
[Login to Remote Accounts] in the System Administration mode. For more information
about [Login to Remote Accounts], refer to
Login Type on page 141 .
Authentication for Job Flow Sheets and Mailboxes
The following explains the restrictions for job flow sheets and mailboxes when the
Authentication feature is enabled.
NOTE: When a user account is deleted, the mailboxes and job flow sheets associated
with the account are also deleted. Any documents stored in the mailboxes will also be
deleted.
NOTE: When the Authentication feature is used with a remote account server, the
user information stored in the machine may be temporarily deleted to restrict user
access. When this happens, the mailboxes and job flow sheets associated with the

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
