Xerox WorkCentre 5230A User Manual

14 Authentication and Account Administration
340
7. Expand the [Security] folder, and then click [Authentication Configuration]. On the
page displayed, place a check mark in the [Enabled] box for each service that you
wish to restrict access to.
8. Click [Next].
9. To configure authentication for each account user, enter an account number in the
[Account Number] box and click [Edit].
10. Fill in the settings for the user.
NOTE: Set [Feature Access] as required. DO NOT set a service to “No Access”,
unless you wish to deny user access to that specific service.
11. Click [Apply].
NOTE: You can also use the control panel on the machine to configure local machine
authentication. The menu path to follow there is: press the <Log In/Out> button, enter
the System Administration mode, press the <Machine Status> button, touch the
[Tools] tab on the screen, and finally touch [Authentication/Security Settings] at the left
side of the menu on the screen. For more details, refer to
Authentication/Security
Settings on page 139
.
Remote Authentication Setup
When [Login to Remote Accounts] is enabled, machine users will be prompted to
provide their user ID and passcode to be validated by the designated authentication
server. If this validation is successful, the machine and any restricted services will be
available for individual use.
Preparations:
1. Ensure the machine is fully functional on the network.
2. Ensure that the TCP/IP, with DNS/WINS enabled, and HTTP protocols are
configured on the machine and fully functional. Refer to those topics in this guide
for configuring information as required. This is required to access CentreWare
Internet Services to configure authentication. CentreWare Internet Services is
accessed through the embedded HTTP server on the machine and allows the
System Administrator to configure Authentication settings by using a web
browser.
3. Ensure the authentication server to be used is functional on your network. Refer
to your manufacturer’s documentation for instructions to complete this task.
At Your Workstation:
1. Open your web browser and enter the TCP/IP address of the machine in the
[Address] or [Location] field. Click [Enter] to access CentreWare Internet Services.
2. Click the [Properties] tab.
3. Expand the [Accounting] folder, and then click [Accounting Configuration]. On the
page displayed, select [Local Accounting] from the [Accounting Type] drop-down
list.
4. Click [Apply] to reboot the machine.
5. Expand the [Security] folder, and then click [Authentication Configuration]. On the
page displayed, select [Login to Remote Accounts] from the [Login Type] drop-
down list.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
