Xerox WorkCentre 5230A User Manual

14 Authentication and Account Administration
316
To enter the System Administration mode, enter the System Administrator ID into the
user ID entry field on the authentication screen.
Authenticated Users (with System Administrator Privileges)
These are users who are assigned System Administrator privileges.
When a restricted service is used, this type of user must enter a user ID on the
authentication screen.
This type of user has the same privileges as the System Administrator for machine
operations, except:
- Operating mailboxes and job flow sheets
- Changing the passcode of the System Administrator.
Authenticated Users (with Account Administrator Privileges)
These are users who are registered on the machine and assigned Account
Administrator privileges.
When a restricted service is used, this type of user must enter a user ID on the
authentication screen.
This type of user has the same privileges as the System Administrator for account
management. They are permitted to register/delete/edit/view account information.
Authenticated Users (with No System Administrator or Account Administrator
Privileges)
These are users who are registered on the machine and assigned no System
Administrator or Account Administrator privileges.
When a restricted service is used, this type of user must enter a user ID on the
authentication screen.
Unauthenticated Users
These are users who are not registered on the machine.
An Unauthenticated User cannot use services that are restricted.
General Users
These are users other than the System Administrator in non-authentication mode.
Types of Authentication
The following three types of authentication are used by the machine depending on
where user information is stored.
Local Machine Authentication
Local Machine Authentication uses the user information registered for the Accounting
feature to manage authentication. Therefore, the Accounting feature must be enabled
when you use Local Machine Authentication. The print or fax data sent directly from a
computer can be received on the machine after being authenticated. The
authentication information pre-configured on a client’s fax print driver is cross-checked
with the information registered on the machine.
Remote Authentication
Remote Authentication uses a remote authentication server to manage authentication.
No user information is registered on the machine.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
