Xerox WorkCentre 5230A User Manual

15 Problem Solving
382
Restrictions
This section explains the restrictions that apply while using EtherTalk.
Machine Name
The machine name recognized by the client cannot have duplicates on the network. If
another machine on the network has the same machine name, the machine name is
changed automatically when the machine starts.
- Name Change Rules
The machine name is changed as follows:
• When the machine name is 31 characters or less in length
A numeral is appended to the end of the machine name. If another machine on the
network still has the same name as the machine, the numeral is incremented.
• When the machine name is 32 characters in length
The last character in the machine name is replaced with a numeral. If another
machine on the network still has the same name as the machine, the numeral is
incremented.
If the [Protocol Settings] in the [Properties] tab of CentreWare Internet Services is
accessed after the machine is initialized with a changed name, the old machine name
is displayed. However, the changed machine name is registered on the network, and
the client can access the machine using the new machine name. If the machine is
switched off and on again after the machine name is changed, the machine attempts
to start with the changed machine name. At this point, if there is another machine on
the network with the same name, the machine name is changed following the rules
above.
It is recommended that all machines on the network be setup with unique machine
names.
Zone Name
The zone name can be set using the [Protocol Settings] in the [Properties] tab of
CentreWare Internet Services. However, if the assigned zone name does not exist on
the network connected to the machine, the zone name is changed to the default zone
name. When setting the zone name, make sure that the zone name exists on the
network connected to the machine.
Bonjour
This section explains the restrictions for Bonjour.
Restrictions
Bonjour operating environment
Bonjour can be used on Macintosh computers running Mac OS X 10.2 or later using
the Printer Setup Utility or Safari. The Bonjour discovery function is enabled on the
same subnet.
Machine Name
• If the machine name or host name settings are changed, print jobs may be printed
on printers other than the specified printer.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
