Xerox WorkCentre 5230A User Manual

14 Authentication and Account Administration
328
Overview of Account Administration
This section is an overview of the Account Administration feature used with the
machine.
Types of Account Administration
The Account Administration feature operates in conjunction with the Authentication
feature when the authentication type is [Login to Local Accounts], and operates
independently when the authentication type is [No Login Required], [Login to Remote
Accounts], or [Xerox Secure Access].
The machine supports the following three Account Administration types.
Local Accounting
Account Administration is performed based on the user information registered on the
machine using a variety of counters automatically created for each user.
Network Accounting
You can perform Account Administration using the user information managed by a
remote server.
This is for unified management of user information and Account Administration by
multiple devices.
Xerox Standard Accounting
Account Administration is performed based on the user information and account
information pre-registered on the machine. Account Administration uses each counter
created automatically for individual users. Auditron reports are created in CSV format
using CentreWare Internet Services. For information on the print driver or fax driver
settings, refer to the online help of each driver. For information on the user information
settings, account information settings, and how to create a report, refer to
Xerox
Standard Accounting on page 334
.
NOTE: When setting the user information or account information for another
WorkCentre 5222/5225/5225A/5230/5230A machine, it is recommended to use the
Cloning feature of CentreWare Internet Services.
Management Features and Services
The following explains the features and services that can be managed using the
Account Administration feature.
Features and Services that Can be Managed with Account Administration
The features and services that can be managed using the Accounting feature vary
depending on whether the user information is stored in the machine or in a remote
account server.
NOTE: For more information on the Accounting feature, refer to
Accounting Type on
page 137
.
• Local Accounting
• Network Accounting
• Xerox Standard Accounting

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
