Xerox WorkCentre 5230A User Manual

10 Scanner Environment Settings
290
Users access the Scan to Home template by selecting the [Network Scanning] button
on the All Services screen on the control panel. The machine queries LDAP to acquire
the authenticated user’s home directory, or uses the network home path predefined on
the machine.
Prerequisites for Scan to Home Setup
1. Ensure the machine is fully functioning on the network prior to installation.
2. Ensure that the TCP/IP and HTTP protocols are configured on the machine and
fully functional. This is required to access CentreWare Internet Services to
configure Network Scanning.
3. Ensure that the SMB port is enabled and the protocol is configured correctly.
4. If required, configure the LDAP protocol for the system (or an authenticated user)
to log in to the LDAP server. LDAP is configured through CentreWare Internet
Services using the following path: open your web browser, enter the IP address of
the machine, click [Properties], click [Connectivity], click [Protocols], and finally,
click [LDAP]. For more information, refer to
CentreWare Internet Services chapter
on page 149.
Procedures for Scan to Home Setup
The Scan to Home feature only works with Remote Authentication.
At Your Workstation:
Enabling Remote Authentication
1. Open your web browser and enter the IP address of the machine in the [Address]
or [Location] field. Click [Enter].
2. Click the [Properties] tab.
3. Click [Security].
4. Click [Authentication Configuration].
5. In the [Login Type] box, select [Login to Remote Accounts].
6. Click [Apply]. The machine will reboot.
Selecting an Authentication System
1. Refresh the web browser.
2. On the [Properties] page, click [Security].
3. Click [Remote Authentication Servers].
4. Click [Authentication System], and then under [Authentication System Settings],
click an authentication system. For more information on the settings for each
authentication system, refer to
Remote Authentication Setup on page 340 .
5. Click [Apply]. The machine will reboot.
Configuring the Scan to Home Settings
1. Refresh the web browser.
2. On the [Properties] page, click [Services].

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
