Xerox WorkCentre 5230A User Manual

Xerox Secure Access Setup
345
Required network communications and server settings will be stated by the server's
manufacturer.
The following is a sample list of setup requirements for Equitrac's Accounting service:
• Enable TCP/IP and HTTP on the machine.
• Set up a static or reserved DHCP IP address for the machine.
• Enable TCP/IP port 80 communications at the machine.
• Download the Controller Interface for Xerox from the Equitrac web site.
• Install the Controller Interface for Xerox at the server.
• Verify that you have purchased a license for the Controller Interface for Xerox, as
well as a license for each device communicating with the server.
• Register each multifunction device at the server (using the device's IP address for
identification).
Enabling the Accounting Option in Workstation Print Drivers
Use the Windows [Add Printer] dialogs to add the machine's print driver to individual,
networked workstations.
In the print driver default setting dialogs, locate and then enable the Accounting option.
This step assures that print jobs from individual workstations will be recognized by the
authentication system, rather than being unrecognized and deleted by the machine.
For Windows operating systems, the default setting dialogs are accessed by right-
mouse clicking on the printer's icon in the [Printers] window for Windows 2000, or in the
[Printers and Faxes] window for Windows XP. Select [Properties] from the displayed
menu, and then locate and enable the Accounting option.
Xerox Secure Access Setup
Xerox Secure Access enables customers to leverage Xerox Partner Solutions to
provide user authentication with an optional card reader. Users can access the features
available at the machine once they have been authenticated.
Secure Access and Accounting
For accounting purposes, Xerox Secure Access works with Network Accounting. To
configure Xerox Secure Access with Network Accounting, refer to
Network
Authentication Setup on page 344
.
NOTE: Secure Access cannot be enabled at the same time as Foreign Device
Interface.
Information Checklist
1. Ensure that the machine is fully functional on the network. TCP/IP and HTTP
protocols must be configured so that Internet Services can be accessed.
2. Ensure that the Xerox Partner authentication solution (Secure Access Server,
Controller, and Card Reader) is installed and communicating with the machine.
Follow the installation instructions from the manufacturer of the authentication
solution to correctly set the devices up.
3. Ensure that SSL (Secure Sockets Layer) is configured on the machine. The Xerox
Partner authentication solution communicates with the machine via HTTPS.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
