Xerox WorkCentre 5230A User Manual

8 Printer Environment Settings
260
SMB Environments
Server Message Block (SMB) is a protocol for sharing files or printers on Windows OS.
This section explains the installation procedure for connecting a printer to a Windows
network through SMB.
System configuration
As the machine supports SMB protocol, you can send print data directly to the machine
on the same network without going through the server.
You can use either NetBEUI, TCP/IP, or even both as the transport protocol for SMB.
You will need to set up the IP address on the machine and the computer if you are using
TCP/IP.
NOTE: Windows XP/Windows Server 2003/Windows Vista do not support NetBEUI.
NOTE: You can make SMB settings through CentreWare Internet Services. For more
information on how to make SMB settings, refer to
CentreWare Internet Services on
page 149
.
Target computers
The following computers support printing through SMB.
NOTE: NetBEUI is not recommended by Microsoft to be used as a protocol in new
networks. It is recommended that this protocol is only used in small networks where
existing legacy clients require it.
SMB Installation
This section describes the installation procedure for using the machine on an SMB
network.
Installation Procedure
The installation procedure is as follows.
Network Communication Setup
Enable the SMB port.
When using NetBEUI:
Set the SMB port to [Enabled] using the touch screen or CentreWare Internet
Services.
Connection OS Protocol
Windows network Windows 95
Windows 98
Windows Me
NetBEUI
TCP/IP
Windows NT 4.0 NetBEUI
TCP/IP
Windows 2000 NetBEUI
TCP/IP
Windows XP
Windows Server 2003
Windows Vista
TCP/IP

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
