Xerox WorkCentre 5230A User Manual

Network-related Problems
379
TCP/IP
This section explains the troubleshooting procedures and restrictions while using
TCP/IP.
Troubleshooting
The possible causes, confirmation methods, and actions are as follows.
When using Windows 2000/Windows XP/Windows Server 2003/
Windows Vista
When printing fails
When the required printing result is not obtained
Cause Confirmation Method Action
The correct IP address is not
specified.
Check whether the IP
address of the machine is
correct.
Specify the correct IP
address for the machine.
When [Receiving Buffer -
LPD] is set to [Spool to
Memory], the size of print
data sent in one print request
exceeds the maximum size
specified.
Check the maximum
receiving data size on the
touch screen of the machine,
and then compare it with the
size of print data to be sent
as one request.
When the print data size
exceeds the maximum size in
one file, divide the file into
smaller files than the
maximum receiving data
size, and then send the print
request again.
When the print data size
exceeds the maximum size in
multiple files, reduce the
number of files to be printed
at one time.
A fault occurred during print
processing.
Check the error message on
the touch screen.
Switch the machine off and
on, and then retry printing.
The selected transport
protocol does not conform
with the client.
Check the selected transport
protocol on the touch screen.
Select a transport protocol
conforming with the client.
The print data format to be
processed by the machine
does not match the data
format sent from the client.
–
Disable the output function of
Ctrl-D.
Cause Confirmation Method Action
The specified print language
is different from the print
language of the print data.
Check the specified print
language and the print
language of the print data.
Specify a print language
matching that of the print
data.
The print driver that
accompanies the machine is
not being used (a third party
print driver is being used).
Check whether the print
driver that accompanies the
machine is selected.
Select the print driver that
accompanies the machine. If
the print driver is not found,
install and select it. If a third
party print driver is used, you
may have unexpected
results.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
