Selecting Transport Protocols
153
Selecting Transport Protocols
When using the NetWare, SMB, or SNMP port, change the transport protocol if
required.
• NetWare: IPX/SPX, TCP/IP
• SMB: NetBEUI, TCP/IP
• SNMP: UDP, IPX
1. On the CentreWare Internet Services home page for the machine, select the
[Properties] tab.
2. In the [Properties] frame, select [Port Status].
3. Select the required transport protocol.
NetWare: IPX/SPX, TCP/IP
SMB: NetBEUI, TCP/IP
SNMP: UDP, IPX
4. Select [Apply].
Screen Layout
The CentreWare Internet Services home
page contains four panels without visible
boundaries. You can change the left and right
panel sizes by dragging the boundary
between them.
Header Panel
Displays the header for all pages. The header
includes the CentreWare Internet Services
logo and the model of the machine. The
header for the WorkCentre 5225A/5230A also
includes a user mode icon, and the name or type of a logged-in user. Just under this
panel on most pages is the tab bar which corresponds to the five functions or page
buttons. These are [Status], [Jobs], [Print], [Scan], [Properties], and [Support]. You can
navigate through the pages when you click the text on each tab.
Logo Panel
Displays the company logo.
Menu Panel
Displays a navigation tree, listing the items available within each category, with the
currently displayed item highlighted.
Header Panel
Main Panel
Menu
Panel
Logo
Panel

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
