Xerox WorkCentre 5230A User Manual

15 Problem Solving
428
Screen Messages
Along with fault codes, the following messages are displayed on the touch screen on
some occasions.
133-210
133-211
133-212
133-213
133-214
133-215
133-216
133-217
133-218
133-219
133-220
133-221
133-222
133-223
133-224
A fax error occurred. Switch off the machine, and then switch it on again.
Contact the Xerox Welcome Center if the problem persists.
133-226 The specified country code is not supported. Contact the Xerox Welcome
Center.
133-280
133-281
133-282
133-283
A fax error occurred. Switch off the machine, and then switch it on again.
Contact the Xerox Welcome Center if the problem persists.
133-700 The staple/punch settings were cancelled. Specify appropriate staple/punch
positions.
133-710 The received fax data was printed using Tray 5 (Bypass), as the selected tray
was not available for fax printing.
134-210
134-211
A fax error occurred. Switch off the machine, and then switch it on again.
Contact the Xerox Welcome Center if the problem persists.
Code Description and Remedy
Message Description and Remedy
A fault has occurred.
Switch off the machine. Ensure that the
screen disappears before switching it on.
If the problem persists, call for service.
A fault has occurred. Switch off the machine
and wait until the touch screen is completely
off, and then restart the machine. If the
problem persists, write down the fault code
(xxx-yyy) displayed on the screen. Switch off
the machine and contact the Xerox Welcome
Center.
A fault has occurred. The machine has
rebooted. If the problem persists, call for
service.
The machine was restarted due to a fault.
Resume normal operations. If the problem
persists, contact the Xerox Welcome Center.
Processing has been cancelled due to an
error.
See User Guide for information on fault code.
The machine operation has stopped due to a
fault. Restart the job.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
