Xerox WorkCentre 5230A User Manual

Scan to PC Setup (FTP)
291
3. Click [Scan to Home].
4. Click [General].
5. On the [Scan to Home] page:
a. On the [Status] line, place a check mark in the [Enabled] box.
b. In the [Friendly Name] box, type in a user-recognizable name of up to 127
characters for the template that will appear in [Template Details] on the
machine’s touch screen.
c. On the [Determine Home Directory] line, select the method of determining the
home directory.
Selecting [LDAP Query] queries the LDAP server with the user’s authenticated
login name and retrieves the user’s home directory to set up the template
scanning path to that directory.
Selecting [No LDAP Query] uses the path specified under [Network Home Path].
d. When [LDAP Query] was selected in step c, click [LDAP Mapping for Home
Directory], and then specify an LDAP home directory.
When [No LDAP Query] is selected in step c, specify a base directory path in
[Network Home Path].
e. If required, create a scanning subdirectory within the user’s home directory, by
enabling [Automatically Create Subdirectory] and then specifying a general
name in [Subdirectory].
f. If required, set [Append “User Name” to Path], [Automatically Create “User
Name” directory if one does not exist], [Directory Structure], and [Use Domain
For Authenticated User].
NOTE: [Use Domain For Authenticated User] is supported by the WorkCentre 5225A/
5230A only.
Scan to PC Setup (FTP)
Files can be scanned on the multifunction machine and routed on to a server or a client
using FTP protocol. Directory structures (repositories) need to be created on the server
to hold the scanned documents.
Prerequisites for Scan to PC Setup (FTP)
1. Confirm that an existing operational network utilizing TCP/IP is available.
2. FTP Server/Client exists and is running.
3. A repository (folder) needs to be created on the FTP server to hold the scanned
document.
4. Confirm that the following ports are enabled:
1) TCP/IP
2) FTP Client
Data to Set Up Scan to PC
(FTP)
Install
Requirement
Comments
Repositories need to be set up on
the FTP server.
Required This is the location or path of the directory
for saving scanned documents.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
