16 Appendix
442
Additional resources may be required on the machine depending on the solution.
For further information, contact your Xerox Sales Representative.
Configuring XEIP
At your workstation
1. Open your web browser.
2. Enter the IP address of the machine in the [Address] or [Location] field.
3. Click [Enter] to access CentreWare Internet Services.
4. Enable the machine for EIP applications:
a) Click the [Properties] tab.
b) Click the [Services] folder, and then the [Custom Services] link.
c) On the [Custom Services] page, select the [Enabled] button.
d) Click [Apply].
5. Generate a digital certificate (if needed):
a) Click the [Properties] tab.
b) Click the [Security] folder, and then the [Machine Digital Certificate
Management] link.
c) Click the [Create New Self Signed Certificate] button. The [Machine Digital
Certificate Management] page refreshes and displays the [Self-Signed
Certificate] area.
d) In the [Self-Signed Certificate] area, click [Apply].
6. Enable SSL:
a) Click the [Properties] tab.
b) Click the [Security] folder, and then the [SSL/TLS Settings] link.
c) If prompted, enter your System Administrator ID and passcode. The default
System Administrator ID and passcode are “11111” and “x-admin” respectively.
d) In the [SSL/TLS Settings] area, on the [HTTP-SSL/TLS Communication] line,
place a check mark in the [Enabled] box.
e) Click [Apply].
f) If changes were made to the SSL settings, the machine will reboot.
7. Enable the ports:
a) Click the [Properties] tab.
b) Click the [Connectivity] folder, and then [Port Settings].
c) On the SNMP line, place a check mark in the [Enabled] box.
d) On the SMB line, place a check mark in the [Enabled] box.
e) On the FTP line, place a check mark in the [Enabled] box.
f) On the SOAP line, place a check mark in the [Enabled] box.
g) Click [Apply].
8. Ensure that TCP/IP is configured:
a) Click the [Properties] tab.
b) Click the [Connectivity] folder, and then the [Protocols] folder.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
