Xerox WorkCentre 5230A User Manual

System Settings
97
• Server Response Time-Out
Specifies the time-out value for a response from the server.
• Search Time-Out
Specifies the time-out value for user search on the server.
Kerberos Server Settings
Specifies the Kerberos servers. The following parameters are available for each
Kerberos server. Use the scroll buttons to switch between screens.
• Kerberos Server 1 to 5
– Primary Server Name / IP Address - Specifies the domain name or IP address of
the primary server.
– Primary Server Port Number - Specifies the primary server port number.
– Secondary Server Name / IP Address - Specifies the domain name or IP address
of the secondary server.
– Secondary Server Port Number - Specifies the secondary server port number.
– Domain Name - Specifies the Kerberos domain name. Enter a domain name up
to 64 characters.
SMB Server Settings
Specifies the SMB server settings.
• SMB Server Setup
Specifies the settings for the SMB server. Select [Domain Name] or [Domain &
Server Names / Address].
• SMB Server 1 to 5
– Domain Name - Specifies the domain name. This setting is mandatory. The
domain name for SMB Server 1 will be the default domain name.
– Server Name / IP Address - Specifies the server name or IP address of up to 64
characters. This setting is effective when [Domain & Server Names / Address] is
selected in [SMB Server Setup].
Security Settings
This feature allows you to set up the security settings.
NOTE: It is necessary to specify the device certificate for the machine in order to
specify the HTTP-SSL/TLS communications and S/MIME settings. For more
information, refer to
Security - Encryption/Digital Signature on page 305 .
1. Select [Security Settings] in the
[Features] menu.
2. Change the required settings.
3. Select [Close].
SSL/TLS Settings
Specifies the SSL/TLS settings.
• Device Certificate - Server
Specifies the server certificate to attach to the e-mail address.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
