Xerox WorkCentre 5230A User Manual

15 Problem Solving
412
024-985 An error occurred in Tray 5 (Bypass). Check the document size, orientation and
paper type, and then try executing the same operation again.
026-700 A protocol which is not supported on the machine was received from the LDAP
server during the address book query. Try executing the same operation again.
Contact the Xerox Welcome Center if the problem persists.
026-701 The number of address book queries exceeded the handling capacity of the
machine. Wait a while, and perform the same operation again. If there was only
one address book query, the problem may be in the machine software. Contact
the Xerox Welcome Center.
026-702 The number of transactions from the LDAP server exceeded the handling
capacity of the machine. Wait a while and perform the same operation. Contact
the Xerox Welcome Center if the problem persists.
027-400 A communication error occurred. If another error message is displayed, clear
the problem first. If the control panel is being used by a user, wait until the user
operation is completed. If the machine is communicating with a remote device,
wait until the communication is completed.
If the problem persists even after you take the above actions, switch off the
machine, and then switch it on again. If the problem still persists, contact the
Xerox Welcome Center.
027-442 The auto stateless IPv6 address 1 of the machine is duplicated on the network.
Change the auto stateless IPv6 address 1 of the machine, or the address of the
other device.
027-443 The auto stateless IPv6 address 2 of the machine is duplicated on the network.
Change the auto stateless IPv6 address 2 of the machine, or the address of the
other device.
027-444 The auto stateless IPv6 address 3 of the machine is duplicated on the network.
Change the auto stateless IPv6 address 3 of the machine, or the address of the
other device.
027-445 The IPv6 address manually set for the machine is invalid. Correct the IPv6
address.
027-446 The IPv6 address manually set for the machine is duplicated on the network.
Change the IPv6 address of the machine, or the address of the other device.
027-447 The link-local IPv6 address of the machine is duplicated on the network.
Change the link-local address of the machine, or the address of the other
device.
027-452 The specified IP address already exists. Change the IP address.
027-500 Unable to resolve the name of the SMTP server when reply e-mail was
transmitted. Check using CentreWare Internet Services to see if the SMTP
server is set correctly.
027-501 Unable to resolve the name of the POP3 server when using the POP3 protocol.
Check using CentreWare Internet Services to see if the POP3 server is set
correctly.
027-502 Unable to log in to the POP3 server when using the POP3 protocol. Check using
CentreWare Internet Services to see if the user name and password used for
the POP3 server are set correctly.
027-503 An error occurred in the POP server. Try again. Contact the Xerox Welcome
Center if the problem persists.
Code Description and Remedy

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
