Rockwell Automation Publication 2711P-UM006A-EN-P - November 2010 11
Chapter
1
Overview
Chapter Objectives
This chapter provides an overview of the PanelView Plus 6 terminals.
PanelView Plus 6 terminals are operator interface devices that run HMI machine-
level applications in an industrial environment. They are used to monitor,
control, or display information graphically, allowing operators to quickly
understand the status of their application.
This platform is programmed using common development software providing
multi-language support, and integrates into systems with Rockwell Automation
controllers including the preferred Logix controllers.
Modular components are usable across the entire PanelView Plus 6 platform:
• Display modules range in size from 6.5 to 15-inches with either key, touch,
or combination key/touch input
• Windows CE logic module runs an open or closed desktop environment
and offers optional, extended features and file viewers
• Optional communication modules for network communication
Topic Page
Windows CE Operating System 12
Open Versus Closed System 12
Desktop Access 13
Software Support 13
Modular Components 14
Configured Terminals 15
Display Modules 16
Catalog Number Explanation 17
Terminal Selections 17
Module Selections 19
Accessories 20
