Allen-Bradley PanelView Plus 6 1250 User Manual

Rockwell Automation Publication 2711P-UM006A-EN-P - November 2010 155
Appendix A
Specifications
Technical Specifications
Table 68 - Technical Specifications - 2711P-Kxxxx8, 2711P-Txxxx8, 2711P-Bxxxx8,
2711P-Kxxxx9, 2711P-Txxxx9, 2711P-Bxxxx9
Attribute
2711P-Kxxxx8, 2711P-Txxxx8, 2711P-Bxxxx8,
2711P-Kxxxx9, 2711P-Txxxx9, 2711P-Bxxxx9
Operating system Microsoft Windows CE 6.0 R3
CPU x86 - 1.0 GHz
Display type Color active matrix, thin film transistor (TFT),
liquid crystal display (LCD)
Display size
700
1000
1250
1500
6.5 in.
10. 4 in.
12.1 in.
15 in.
Display area (WxH)
700
1000
1250 and 1250 high-bright
1500
132 x 99 mm (5.2 x 3.9 in.)
211 x 158 mm (8.3 x 6.2 in.)
246 x 184 mm (9.7 x 7.2 in.)
304 x 228 mm (12.0 x 9.0 in.)
Resolution
700
1000
1250 and 1250 high-bright display
1500
640 x 480, 18-bit color graphics
640 x 480, 18-bit color graphics
800 x 600, 18-bit color graphics
1024 x 768, 18-bit color graphics
Luminance, typical
700 to 1500
1250 high-bright
300 cd/m
2
Nits
1000 cd/m
2
Nits
Backlight
700 to 1500
1250 high-bright
CCFL 50,000 hours life, min
Backlight not replaceable
Touch screen
Actuation rating
Operating force
Analog resistive
1 million presses
10…110 g
Keypad function keys
(1)
Actuation rating
Operating force
Function keys, numeric and navigation
1 million presses
340 g
Real-time clock Battery-backed, +/-2 minutes per month
Battery life is 4 years min at 25 °C (77 °F)
Memory 512 MB nonvolatile flash, 512 MB RAM
Secure digital (SD) card 1 GB or 2 GB, cat. no. 1784-SD1 or 1784-SD2
Status indicators COMM (green), Fault (red)
